How to Build and Push Docker Image to GitLab, ACR, ECR, JFrog Artifactory, Dockerhub through GitHub Actions Using Terraform Packer

In the evolving landscape of DevOps, automating the build and deployment of containerized applications is crucial. Terraform Packer, in combination with GitHub Actions, allows you to automate the creation and deployment of Docker images to different container registries like GitLab, Azure Container Registry (ACR), AWS Elastic Container Registry (ECR), JFrog Artifactory, and DockerHub. In this guide, I’ll show you how to build and push Docker images using Terraform Packer and GitHub Actions.

1. Introduction

Packer is a powerful tool that allows you to automate the creation of images, including Docker containers. By integrating Packer with GitHub Actions, you can automate the building of Docker images and push them to different container registries. This saves time and ensures a consistent deployment process across environments.

In this article, we’ll explore how to build and push Docker images using Terraform Packer and GitHub Actions to various platforms, such as GitLab, ACR, ECR, JFrog Artifactory, and DockerHub.

2. Prerequisites

Before you get started, ensure you have the following:

• Packer: Installed on your local machine and configured for Docker.
• Terraform: Installed and set up.
• GitHub Repository: A repository where you’ll configure GitHub Actions.
• GitLab, ACR, ECR, JFrog, DockerHub Accounts: You’ll need credentials to push Docker images.
• Access Tokens or Credentials: Store these credentials securely using GitHub Secrets.
• Follow Us On Medium:-Medium

3. Setting Up GitHub Actions with Terraform Packer Deploying Docker Hub

First, you’ll need to create a GitHub Actions workflow file in your GitHub repository. This workflow will automate the process of building a Docker image using Packer and then pushing the image to a container registry.

Below is an example of a GitHub Actions .yml file for building a Docker image using Packer:

name: Build and Push Docker Image using Packer

on:
  push:
    branches:
      - main

jobs:
  build:
    runs-on: ubuntu-latest
    steps:
      - name: Checkout Code
        uses: actions/checkout@v2

      - name: Install Terraform and Packer
        run: |
          sudo apt-get update && sudo apt-get install -y unzip
          curl -LO https://releases.hashicorp.com/terraform/1.4.2/terraform_1.4.2_linux_amd64.zip
          unzip terraform_1.4.2_linux_amd64.zip
          sudo mv terraform /usr/local/bin/
          curl -LO https://releases.hashicorp.com/packer/1.7.8/packer_1.7.8_linux_amd64.zip
          unzip packer_1.7.8_linux_amd64.zip
          sudo mv packer /usr/local/bin/

      - name: Build Docker Image using Packer
        run: |
          packer init packer-config.pkr.hcl
          packer build packer-config.pkr.hcl

      - name: Log in to DockerHub
        run: echo "${{ secrets.DOCKERHUB_PASSWORD }}" | docker login -u "${{ secrets.DOCKERHUB_USERNAME }}" --password-stdin

      - name: Push Docker Image
        run: docker push my-app:${{ github.sha }}

This workflow sets up Terraform and Packer, builds a Docker image, and pushes it to DockerHub. Let’s now focus on pushing to different registries.

4. Build and Push to GitLab Container Registry Using Packer

GitLab Container Registry allows you to host your Docker images. Here’s how you can automate the build and push process:

1. Create a Personal Access Token in GitLab with api and write_registry permissions.
2. Add the token to your GitHub Secrets as GITLAB_TOKEN.

Update the previous workflow to push images to GitLab:

name: Push Docker to GitLab Using Packer

on:
  push:
    branches:
      - main

jobs:
  build:
    runs-on: ubuntu-latest
    steps:
      - name: Checkout Code
        uses: actions/checkout@v2

      - name: Install Terraform and Packer
        run: |
          sudo apt-get update && sudo apt-get install -y unzip
          curl -LO https://releases.hashicorp.com/packer/1.7.8/packer_1.7.8_linux_amd64.zip
          unzip packer_1.7.8_linux_amd64.zip
          sudo mv packer /usr/local/bin/

      - name: Build Docker Image using Packer
        run: packer build packer-config.pkr.hcl

      - name: Log in to GitLab Container Registry
        run: echo "${{ secrets.GITLAB_TOKEN }}" | docker login registry.gitlab.com -u <username> --password-stdin

      - name: Push Docker Image to GitLab
        run: docker push registry.gitlab.com/<username>/<repo>:latest

5. Build and Push to Azure Container Registry (ACR) Using Packer

Azure Container Registry (ACR) is a fully managed private registry for Docker containers. To push Docker images to ACR using Packer, follow these steps:

1. Log in to Azure using the Azure CLI.
2. Add your Azure credentials to GitHub Secrets (AZURE_CLIENT_ID, AZURE_CLIENT_SECRET, AZURE_TENANT_ID).

Here’s an example workflow:

name: Push Docker to ACR Using Packer

on:
  push:
    branches:
      - main

jobs:
  build:
    runs-on: ubuntu-latest
    steps:
      - name: Checkout Code
        uses: actions/checkout@v2

      - name: Install Terraform and Packer
        run: |
          curl -LO https://releases.hashicorp.com/packer/1.7.8/packer_1.7.8_linux_amd64.zip
          unzip packer_1.7.8_linux_amd64.zip
          sudo mv packer /usr/local/bin/

      - name: Log in to Azure CLI
        run: az login --service-principal -u ${{ secrets.AZURE_CLIENT_ID }} -p ${{ secrets.AZURE_CLIENT_SECRET }} --tenant ${{ secrets.AZURE_TENANT_ID }}

      - name: Build Docker Image using Packer
        run: packer build packer-config.pkr.hcl

      - name: Push Docker Image to ACR
        run: docker push <ACR_REGISTRY_NAME>.azurecr.io/my-app:latest

6. Build and Push to AWS Elastic Container Registry (ECR) Using Packer

To push Docker images to AWS Elastic Container Registry (ECR), you’ll need to set up your AWS credentials (AWS_ACCESS_KEY_ID, AWS_SECRET_ACCESS_KEY) in GitHub Secrets.

Here’s the workflow:

name: Push Docker to ECR Using Packer

on:
  push:
    branches:
      - main

jobs:
  build:
    runs-on: ubuntu-latest
    steps:
      - name: Checkout Code
        uses: actions/checkout@v2

      - name: Install Terraform and Packer
        run: |
          curl -LO https://releases.hashicorp.com/packer/1.7.8/packer_1.7.8_linux_amd64.zip
          unzip packer_1.7.8_linux_amd64.zip
          sudo mv packer /usr/local/bin/

      - name: Log in to AWS ECR
        run: |
          aws configure set aws_access_key_id ${{ secrets.AWS_ACCESS_KEY_ID }}
          aws configure set aws_secret_access_key ${{ secrets.AWS_SECRET_ACCESS_KEY }}
          aws ecr get-login-password --region us-west-1 | docker login --username AWS --password-stdin <AWS_ACCOUNT_ID>.dkr.ecr.us-west-1.amazonaws.com

      - name: Build Docker Image using Packer
        run: packer build packer-config.pkr.hcl

      - name: Push Docker Image to ECR
        run: docker push <AWS_ACCOUNT_ID>.dkr.ecr.us-west-1.amazonaws.com/my-app:latest

7. Build and Push to JFrog Artifactory Using Packer

To push Docker images to JFrog Artifactory using Packer, follow these steps:

1. Set up API tokens in JFrog.
2. Store credentials in GitHub Secrets.

Here’s the workflow:

name: Push Docker to JFrog Artifactory Using Packer

on:
  push:
    branches:
      - main

jobs:
  build:
    runs-on: ubuntu-latest
    steps:
      - name: Checkout Code
        uses: actions/checkout@v2

      - name: Install Packer
        run: |
          curl -LO https://releases.hashicorp.com/packer/1.7.8/packer_1.7.8_linux_amd64.zip
          unzip packer_1.7.8_linux_amd64.zip
          sudo mv packer /usr/local/bin/

      - name: Build Docker Image using Packer
        run: packer build packer-config.pkr.hcl

      - name: Log in to JFrog Artifactory
        run: echo "${{ secrets.JFROG_PASSWORD }}" | docker login <JFROG_REGISTRY_URL> -u "${{ secrets.JFROG_USERNAME }}" --password-stdin

      - name: Push Docker Image to JFrog Artifactory
        run: docker push <JFROG_REGISTRY_URL>/my-app:latest

8. Conclusion

Using Terraform Packer with GitHub Actions to automate the building and pushing of Docker images to container registries streamlines the DevOps process. Whether you’re deploying to GitLab, Azure ACR, AWS ECR, JFrog Artifactory, or DockerHub, Packer provides a consistent and efficient approach.

By automating these workflows, you ensure faster delivery, minimize human error, and maintain consistent builds across all environments.
